CBB61 5uF Ceiling Fan Capacitor 450V AC 25/70/21 ±5% 50/60Hz Cylinder 47x17.5x34.5mm with 2 Wires Metalized Polypropylene Film Capacitors for Water Pump Motor Generator,2 PCS
5.0 (135 items)
Limited Time SaleUS$3.05 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 250269677 | Release Date | 2026/09/17 | List Price | US$2.04 | Model Number | 250269677 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Welcome to BOXONLY! BOXONLY will be your best partner and bring you the best product experience! Description: 1)Rated voltage: 450V AC; 2)Rated capacitance: 5uF; 3)External dimensions: 47x34x22mm; 4)Case Material: ABS,PBT, Non-reformed plastics 5)Tolerance: ±5%; 6)Rated frequency: 50/60Hz; 7)Climate Category: 25/70/21 8)Insulation resistance: ≥3000S (MΩ.μF) 9)Loss angle tangent: tgδ≤0.002(100Hz～1000Hz)
- [Specifications]: Rated Capacity: 5uF; Tolerance: ±5%; Rated Voltage: 450V AC; Cover Size: 47x17.5x34.5mm; Rated Frequency: 50/60Hz; Temperature Range: 25/70/21
- [Stable]: Good performance stability, shock current resistance, high temperature resistance, long service life.
- [Operating Environment]: This CBB61 capacitor is applied to starting and working of a single-phase motor in a 50Hz/60Hz AC electric power system
- [Application]: The CBB61 capacitor is widely used for ceiling fan, wall fan, stand fan, industrial fan, range hood fan, air exchange fan, water pump, motor, generator, etc.
- [Characteristics]: The ceiling fan capacitor is made of metallized polypropylene film sheet with plastic shell. CBB61 operating capacitors feature low loss, high temperature resistance, excellent electrical performance and long service life.
| ASIN | B0CR4B3FM8 |
|---|---|
| Model | Capacitor2-1-1 |
| Brand Name | Boxonly |
| Item Shape | Cylindrical |
| Unit Count | 2 Count |
| Capacitance | 5 microfarad |
| Part Number | Capacitor2-1-1-02 |
| Manufacturer | Boxonly |
| Material Type | Polyester |
| Mounting Type | Through-Hole Mount |
| Number of Items | 2 |
| Number of Packs | 2 |
| Operating Voltage | 450 volts_of_alternating_current |
| Included Components | capacitor |
| Upper Temperature Rating | 70 °C |
| Maximum Storage Temperature | 70 °C |
